86 Inches Interactive Panel

86 Inches Interactive Panel Premium Series

WeeTaach is a trust-worthy touch control panel series of Guangzhou Ruixin Touch Control Technology Co., Ltd. developed for overseas users. With the highest configurations among the industry, the responsive and smooth operations of the devices are guaranteed. We believe in quality and honesty. The following is the description of WeeTaach 86 inches interactive panel Premium series.

Background: we provide standard series of WeeTaach 06B smart panels with wall mount brackets, WeeTaach 06B Pro series with mobile stands, as well as WeeTaach 06B Premium series with auto-stands. Interactive touch smart panels, or touch screens, smart screen displays, IR touch control monitors, All-in-one interactive whiteboards, virtual whiteboards, whatever you name them, they`re the mainstream touch control display devices widely used in classroom education & business conference system. Projectors + traditional whiteboards or soft curtains are too old and no longer have the advantages even in terms of prices. While the capacitive touch LED screens are still high in the air, and their prices are as much as 5 to 10 times of the IR touch screens.

Related Products:

1. 55 inches Smart Panel
2. 65 inches large-size smart panel
3. 70 Inches Interactive Smart PC With Mobile Stand
4. 75 Inches Touch Panel With Mobile Stand
5. 86 Inches Interactive Panel With Mobile Stand
6. 55 Inches Infra-Red Screen With Automatic Stand
7. 65 Inches Smart LCD Panel With Automatic Stand
8. 70 Inches Interactive Whiteboard With Automatic Stand

I. Main Features:

• User-experience-oriented and quality-first design & manufacture;
• 20 years` focus on inspiring education, interactive & collaborative meeting;
• Powerful Android OS, and Windows OS (Optional);
• Reliable, accurate and responsive multi-touch screen;
• 4K UHD crystal clear display, anti-glare, regardless of environmental lighting;
• Intuitive & user-friendly interfaces and buttons at front and backside;
• Smart & fluent wireless screen sharing of mobile, pad, laptop and even desktop;
• Energy-saving design, one-button shut down, and double-click to wakeup screen;
• Certifications: ISO9001, CE, FCC, CCC, RoHS etc.;
• Seeking win-win cooperation, once a deal leads to permanent partnership.

II. Product Illustration:

III. Main Parameters:

1. Display

• Screen size: 86 inches
• Screen type: LED back lighted
• Max. display size (mm): 1872 (H) x 1053 (V)
• Resolution (pixel): 3840 (H) x 2160 (V)
• Display ratio: 16:9
• Brightness: More than 350cd/m2
• Contrast (static): 1200:1
• Viewing angle: 178° x 178°（H/V）
• Touch Surface: Tempered glass ( anti-glare & explosion-proof)
• Life span: More than 60000 hours

2. Touch control system

• Touch mode: Infrared recognition
• Response time: Less than 8 ms
• Touch media: More than 5 mm (opaque objects i.e. fingers or stylus)
• Multi-touch: Yes (10 touches)

3. Android system

• OS version: Android 8.0 or above
• RAM: 4 G
• Storage memory: 32 G

4. PC system (OPS module, Optional)

• CPU: Intel i7
• OS: Win 7/10, or customized
• RAM: 8 G
• Hard disk (SSD): 256 G
• Graphics card: Integrated Graphics
• Sound card: Integrated high-definition stereo sound card
• Network card: Integrated 10/100/1000M adaptive network card
• Wi-Fi: Wireless network card 802.11b/g/n

5. Power supply

• Input power: AC 100 to 240V, 50/60 Hz (self-adaption)
• Power consumption: 450 W
• Standby consumption: Less than 0.5 W (main board power off)

6. Size and weight

• Machine size: 2013x1220.8x112.4mm (length x width x thickness)
• Package size: 2183x270x1391mm (length x thickness x height)
• Net weight: 86 kg
• Gross weight: 106 kg

Note: The technical specifications herein are for reference only. We remain the rights to upgrade without prior notice.

Product Categories : Smart Panel > Type RXZG-8606B
